MG-600 - Spare Parts Catalogue

General assembly

#	PART NUMBER	DESCRIPTION	QTY	REMARKS
1	MG-600-01-001	MAIN FRAME, WELDED ASSY	1
2	MG-600-01-005	ROTATOR FRAME, WELDED	1
3	MG-600-01-002	GRAPPLE SHELL, LH	1
4	MG-600-01-003	GRAPPLE SHELL, RH	1
5	MG-600-04-001	LINKAGE ASSY	1
6	MG-500-02-009	SLEWING RING	1
7	MG-1050-02-001	HYDRAULIC MOTOR	1
8	MG-1050-02-006	HYDRAULIC CENTER JOINT ASSEMBLY	1	see separate chapter
9	MG-600-03-001	CYLINDER	1	see separate chapter
10	MG-600-02-003	LOCK NUT, MOTOR	1
11	MG-1050-02-002	PINION	1
12	MG-600-02-008	ANTI-ROTATION PLATE	1
13	MG-600-04-004	BOLT	2
14	MG-600-04-002	BOLT	2
15	MG-600-07-004	EXTENDED ADAPTOR	1
16	MG-600-04-007	WASHER	4
17	MG-600-04-005	BEARING BUSH	1
18	MG-600-04-009	COTTER PIN	4	Ø6.3×65
19	MG-600-04-010	SLOTTED NUT	4	M30×2
20	MG-450-01-006	WEAR BLADE, REPLACEABLE	2
21	MG-600-06-001	DUST SEAL	1
22	MG-600-04-006	BEARING BUSH	4	Ø50×Ø60-60
23	MG-600-07-009	PLUG	2	G1/2
24	MG-600-07-001	ADAPTOR	4	G1/2
25	MG-600-07-010	PLUG	2	G3/8
26	MG-600-07-002	REDUCER ADAPTOR	4	G1/2–G3/8
27	MG-600-07-005	EXTENDED ADAPTOR	1
28	MG-600-07-008	HOSE, HYDRAULIC	1
29	MG-600-07-007	HOSE, HYDRAULIC	1
30	MG-600-05-012	SCREW, HEX SOCKET HEAD CAP	4	M12×80
31	MG-600-05-011	NORD-LOCK WASHER	4	M12
32	MG-600-05-013	SCREW, HEX SOCKET HEAD CAP	4	M12×25
33	MG-600-05-014	NORD-LOCK WASHER	4	M12
34	MG-600-05-017	SCREW, HEX SOCKET HEAD CAP	2	M10×25
35	MG-600-05-018	WASHER, EXTERNAL SERRATED LOCK	2	M10
36	MG-600-05-001	SCREW, HEX SOCKET HEAD CAP	40	M16×70
37	MG-600-05-002	NORD-LOCK WASHER	40	M16
38	MG-600-07-006	90° ELBOW ADAPTOR	2
39	MG-450-05-016	SCREW, HEX SOCKET HEAD CAP	12	M16×35, ISO 4762
40	MG-450-05-017	HEX NUT	12	M16, ISO 4032
41	MG-600-07-003	GREASE NIPPLE	12	M10×1
42	MG-1050-02-007	RELIEF VALVE ASSEMBLY	1	Set at 14 bar; see separate chapter
43	MG-600-07-012	REDUCER ADAPTOR	4	G1/2–G1/4
44	MG-600-07-014	REDUCER ADAPTOR	2	G3/4–G1/2

Hydraulic Center Joint Assembly

#	PART NUMBER	DESCRIPTION	QTY	REMARKS
—	MG-1050-02-006	HYDRAULIC CENTER JOINT ASSEMBLY	1
101	MG-1050-02-101	CENTER JOINT HOUSING	1
102	MG-1050-02-102	CENTER JOINT ROTOR	1
103	MG-1050-02-103	CENTER JOINT COVER	1
104	MG-1050-02-104	SCREW, HEX SOCKET HEAD CAP	4	M8×20
105	MG-1050-02-105	SEAL KIT, COMPLETE	1

Hydraulic cylinder · pos. 9

#	PART NUMBER	DESCRIPTION	QTY	REMARKS
—	MG-600-03-001	CYLINDER	1	assembly
201	MG-600-03-201	CYLINDER BODY	1
202	MG-600-03-202	ROD	1
203	MG-600-03-203	COVER	1
204	MG-600-03-204	PISTON	1
205	MG-600-03-205	SEAL KIT, COMPLETE	1
206	MG-600-03-206	GREASE NIPPLE	2
207	MG-600-03-207	BEARING BUSH (CYLINDER)	2	Ø45×Ø55-25
208	MG-600-03-208	PLUG	2

Relief Valve Assembly

#	PART NUMBER	DESCRIPTION	QTY	REMARKS
—	MG-1050-02-007	RELIEF VALVE ASSEMBLY	1
1	MG-1050-02-301	VALVE BLOCK	1
2	MG-1050-02-302	RELIEF VALVE	1	LBRV2-10-30
3	MG-1050-02-303	G1/4 PLUG	2	4BN-04WD
4	MG-1050-02-304	G1/8 PLUG	3	4BN-02WD
5	MG-1050-02-305	G1/2-L57 HOLLOW BOLT	2	STANDARD
6	MG-1050-02-306	G1/2 BONDED SEAL	4	STANDARD
